FR - BLIND DOOR IP66
The FR range of stainless steel modular cabinets is made in compliance with the most recent international standards and according to deeply innovative constructive concepts of protection, solidity and design.
Available in single door configuration up to W=1000mm. The IP66 rating, the removable rear side also replaceable with a door, and the scotch-brite finish characterize the FR series as the ideal solution for applications in aggressive environments such as in the food, chemical, and pharmaceutical industries, or for applications in outdoor environments.
Upon request, it is possible to supply our FR modular cabinets tailormade according to the costumer’s needs.
Every cabinet of the ARMOD range comes with Fe/zn mounting plate (code PI…), removable cable entry flange and lifting eyebolts as standard and included in the cabinet’s price.
TECHNICAL SPECIFICATIONS
Material: AISI 304L stainless steel 15/10 – AISI 316L stainless steel 15/10 upon request
Method of installation: floor-mounted
Protection degree: IP66
UL label upon request – Nema Type 1, 12, 4, 4X
Protection degree: IK10
Installation: indoor/outdoor
Standard polyurethane seal – silicone seal upon request
Door reinforcement frame fixed with glue and hardware
Side-entry mouting plate , removable side panels, cabinet profiles with 25mm spacing drills
ACCESSORIES
- PI – NARROW MOUNTING PLATES
- PIFR – WIDE MOUNTING PLATES
- PIA – PARTIAL PLATES
- TC – INNER DOOR KITS
- TR – 19″ RACK SUPPORT FRAMES
- TPA – RAIN CANOPIES
- TM – MODULAR FRAMES + MODULAR PANELS
- FLG – DOUBLE ENTRY FLANGES
- TS – WIRING PLAN POCKETS
- FZ – PLINTHS
- PL – COMPONENT SHELVES
- PDP – FEET FOR PLINTHS
- CF – PAIR OF SIDE PANELS
- KU – CABINET JOINING KITS
- PSO/PSV – HORIZONTAL/VERTICAL SEPARATION WALLS
- BARS KITS
- PP/PPT – PROTECTION-INSPECTION WINDOWS
- VC – CABLE COMPARTMENTS
