FD SERIES JUNCTION BOXES IP66 AND IP68
Ideal solutions for installation in aggressive environments such as in the food, chemical, and pharmaceutical industry as well as application in outdoor environments.
Upon request, it is possible to supply our FD Boxes tailormade according to the costumer’s needs.
Mounting plates are not included in the FD Boxes. They are sold separately and upon request.
TECHNICAL SPECIFICATIONS
Material: AISI 304L stainless steel 12/10 – AISI 316L stainless steel 12/10 upon request
Method of installation: floor-mounted / wall-mounted
Protection degree: IP66 / IP68 for codes FDS
UL label upon request – Nema Type 1, 12, 4, 4X (except for models FD406015 and FD606020)
Protection degree: IK10
Installation: indoor/outdoor
